Sibo занимается потенциометрами и датчиками уже 30 лет.

HC70FCA
HC70FCA

HC70FCA

Magnetic-type Pedals

瀏覽量： Вернуться: 2023-01-09

    Характеристики：

  • Hall effect IC type

  • Single or double full redundant outputs

  • Metal case with high reliability

Измерение


Параметр

General Specifications

Operating angle

Approx.22°

Operating force

15～27N

Mechanical life expectancy

5,000,000 operations

Operating temperature

-30℃~+70℃

Storage temperature

-30℃~+70℃

Vibration

10~55Hz 98m/s²

Shock

294m/s²

Mass

Approx.1100g

Protection degree

IP67（Electrical parts）

Electrical Specifications (Hall Effect Potentiometer)

Electrical Specifications

S1，R1，R2，R3，R4

Applied voltage

5V±10%，5V±10% ，9V~30V，15V~30V，15V~30V

Output Signal

0.5V~4.5V，0~5V，0~5V，0~10V，4~20mA

Current consumption (no-load)

<16mA，<16mA，<25mA，<25mA，<35mA

Output deviation at both ends

<1%.VCC，<1%.VCC，<50mV，<50mV，<0.1mA

Load resistance

>100KΩ，>100KΩ，>100KΩ，>100KΩ，<600Ω

Effective electrical angle

Approx. 60°

Independent linearity tolerance

±2%

Resolution

4096 (12 Bit)

Update rate

0.3ms

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

Terminal Connection Instructions

Color

Red，Black，White

Title

VCC，GND，OUT

Special Specifications Available

Other output signals

PWM

Electrical specifications

Special output characteristic, speical cable length, etc.
