Standard Resistance Range
500Ω~10KΩ
Max. Practical Resistance Value
20KΩ
Total Resistance Tolerance
Standard Class ±10%(K), Precision Class ±5%(J)
Independent Linearity Tolerance
Standard Class ±2.0%, Precision Class ±0.5%
Power Rating
0.75W
Noise
<100Ω E.N.R.
Electrical Travel
280°±5°
Mechanical Travel
360°Endless
Insulation Resistance
>100MΩ(1000V.D.C.)
Dielectric Strength
1 minute at 1,000V.A.C.
Starting Torque
<30mN·m(300gf·cm)
Resistance Temperature Coefficient
±20p.p.m./℃
Mass
Approx. 40g
Special resistance value
Special lower practical resistance values (50Ω to 200Ω )
Special shaft type
Shaft dia. (φ 3.175mm)&bushing with inch dimension, special machining on the shaft
Special electrical travel
Special electrical travel
Special tap
Extra tap (Available up to 1 tap)
With stopper
Rotating angle is 300°and stopper strength is 0.3N?m [3kgf?cm]
