Single turn
Wirewound
Bushingmount
Low-cost Item
Standard Resistance Range
50Ω～10KΩ
Max. Practical Resistance Value
20KΩ
Total Resistance Tolerance
Standard Class ±3%(H), Precision Class±1%(F)
Independent Linearity Tolerance
Standard Class ±0.5%, Precision Class±0.25%, (±0.3％ in case of within 1kΩ )
Power Rating
0.5W
Noise
<100ΩE.N.R.
Electrical Travel
355°±5°
Mechanical Travel
360°(Endless)
Insulation Resistance
>1000MΩ(1000V.D.C.)
Dielectric Strength
1 minute at 1,000V.A.C.
Starting Torque
<5mN·m(50gf·cm)
Resistance Temperature Coefficient
±20p.p.m./℃
Mass
Approx.23g
Special resistance value
Lower resistance values (10Ω , 20Ω )
Special shaft type
Shaft with front and rear extension (Rear shaft with 3mm dia. and 20mm length), shaft dia. (φ 6.35mm) ＆ bushing with inch dimension, special machining on the shaft
Special electrical travel
Special electrical travel
Special tap
Extra tap (Available up to 1 tap)
With stopper
Rotating angle is 320°and stopper strength is 0.9N?m [9kgf?cm])
